Equil® Academy – Master Your Pump with Confidence
Module 3: Step-by-Step Placement & Start
A quick, safe install from site prep to first delivery.
- Choose one of 10 body sites (rotate); clean with additive-free medical alcohol; air-dry.
- Stick the pump base; load cannula in inserter; place under base ridge; press to skin; press the two orange buttons to insert; press the white button to release the tool.
- Fill the reservoir slowly; remove bubbles; detach the outer ring and pull-rod.
- Insert a fully charged battery into the reservoir; assemble reservoir + pump until you feel side locks and hear a sound.
- Prime until a drop appears; attach pump to the base until a click; choose Fill Cannula only when the base was changed (otherwise Skip).
More Modules to Choose From
Why Equil®? Freedom Meets Control
Equil® Pump — Frequently Asked Questions
Equil® begins smart control immediately—no long “learning” period. The system delivers smooth, adaptive basal from the first wear, so you feel the benefits right away.
Yes. Equil® is a CE-marked, tubeless patch pump for insulin-requiring adults, designed for discreet, comfortable wear and everyday automation when used with a compatible CGM.
Yes. It delivers tiny basal micro-doses 24/7 that act like long-acting insulin—plus precise mealtime boluses.
Yes you’ll use U‑100 rapid-acting insulin to fill the Equil® reservoir and keep a backup pen/vial per your clinic’s guidance.
Equil® SmartStart training gets you pump-ready fast: diabetes basics, carb-counting confidence, and hands-on setup—so your transition feels smooth and supported.
No. The pump talks directly to the CGM sensor, so closed-loop automation continues even when the PDA isn’t nearby. The PDA is for viewing, setup, and quick changes.
No. The pump and sensor both store readings. When the PDA is back in range, everything syncs automatically for a complete history.
The system will correct after it detects a rise, but pre-bolusing usually keeps peaks lower and steadier.
Yes—Quick Bolus on the pump lets you dose discreetly when the PDA isn’t handy.
Approved sites include the upper arm or abdomen—choose the locations that fit your routine.
Yes—enable secure sharing so caregivers and clinicians can coach proactively.
No. Looping runs locally via pump↔sensor. Internet is only for cloud sync and remote sharing.
IPX8 when assembled (up to 1 m for 1 hour). Rinse, dry, and inspect after water. The PDA is IPX4 (splash-proof).
Up to 15 days—plan 2 sensors per month per user.
Reservoirs and infusion sets (cannula + base) are sold separately in boxes of 10.
About every 3 days, and rotate sites to support consistent absorption and skin recovery.
Equil® adjusts background insulin in real time to reduce highs/lows. You remain in charge of meal boluses for best post‑meal outcomes.
No. It adapts from day one using trend‑aware control to smooth day‑to‑day variability.
The system manages safely and resumes automation once signal returns. You’ll get clear prompts to keep you informed.
It combines carbs, current glucose, and your settings, then subtracts Active Insulin to suggest a smart dose fast and fewer guesswork moments.
Use smaller, timely boluses and favorites to keep decisions quick while avoiding stacking.
Follow your CGM’s guidance. If calibrations are optional, use them sparingly and only when needed for accuracy.
It’s engineered to reliably deliver a full reservoir of insulin before needing a swap, regardless of whether you use it in ~3 days or longer.
